规格
30HXC250E
- 可见性
- Maintenance Zone Front Visibility 0
- Maintenance Zone Bottom Visibility 0
- Clearance Zone Visibility 0
- Maintenance Zone Top Visibility 0
- Maintenance Zone Left Visibility 0
- Maintenance Zone Back Visibility 0
- Maintenance Zone Right Visibility 0
- 尺寸标注
- Maintenance Zone Back Depth 1050mm
- H 1785mm
- Y2 720mm
- F 1107mm
- A1 320.5mm
- B1 178.5mm
- A 284mm
- Y3 600mm
- G 364mm
- S1 75mm
- Y4 420mm
- R3 98.68730755496mm
- L2__ve -3635mm
- Y5__ve -300mm
- E1 200mm
- W1 525mm
- R1 100mm
- Maintenance Zone Under Depth 1785mm
- Y5 300mm
- W3 3150mm
- L2 3635mm
- A2 272.425018310547mm
- S 150mm
- MZONU__ve -1785mm
- R 200mm
- Maintenance Zone Right Depth 3915mm
- L3 11745mm
- L2D 99.9999999999999mm
- Y3__ve -600mm
- Y4__ve -420mm
- E3 3.5mm
- W2D 99.9999999999999mm
- R2 80mm
- B 357mm
- L2D_Min 0mm
- Maintenance Zone Over Depth 3570mm
- C2 296.225006103516mm
- Maintenance Zone Left Depth 3915mm
- L1 1957.5mm
- C 340mm
- C1 348.5mm
- E 2060mm
- Maintenance Zone Front Depth 1050mm
- Y2__ve -720mm
- D 309mm
- 标识数据
- 型号 ---
- 类型注释 ---
- 成本 ---
- URL ---
- 制造商 ---
- 部件代码 ---
- 类型图像 ---
- 注释记号 ---
- 说明 ---
- 图形
- Use Minimum Symbol Size 0
- 机械
- MC Flow Factor 1
分类
模型格式 rfa
适配软件
特点
上传时间 2020-06-28
构件有问题？点我反馈
构件品牌 开利空调
