规格
19XR- 7P70E53MDB52
- 尺寸标注
- L2D_Min 0mm
- R1 150mm
- R13 290.5mm
- F 1048mm
- A11 1046.5mm
- C2 675.5mm
- AA1__ve -476mm
- L2D 99.9999999999999mm
- B22 1207mm
- AA1 476mm
- R3 150mm
- C6 652.950012207031mm
- Maintenance Zone Right Depth 5731mm
- R5 180mm
- Maintenance Zone Front Depth 2712mm
- DI4 300mm
- B5 603mm
- W3 7278mm
- C10 470.5mm
- R10 370.5mm
- W2D 99.9999999999999mm
- R12 465.5mm
- DI1 300mm
- I 2134mm
- B11 1219mm
- Maintenance Zone Left Depth 5731mm
- E1 254mm
- A1 2522.5mm
- E 1556mm
- DI2 300mm
- G1 254mm
- R4 150mm
- C1__ve -1451mm
- R11 410.5mm
- Maintenance Zone Back Depth 2712mm
- B2 609mm
- DI3 300mm
- AA 302mm
- B4 487.200012207031mm
- C__ve -2902mm
- G 1314mm
- A2 4267mm
- B2__ve -609mm
- B3 608mm
- C1 1451mm
- L3 15135mm
- R2 150mm
- C 2902mm
- H 806mm
- 可见性
- Clearance Zone Visibility 0
- Maintenance Zone Bottom Visibility 0
- Maintenance Zone Left Visibility 0
- Maintenance Zone Right Visibility 0
- Maintenance Zone Top Visibility 0
- Maintenance Zone Back Visibility 0
- Maintenance Zone Front Visibility 0
- 标识数据
- 类型注释 ---
- 类型图像 ---
- URL ---
- 制造商 ---
- 注释记号 ---
- 成本 ---
- 型号 ---
- 说明 ---
- 部件代码 ---
- 图形
- Use Minimum Symbol Size 0
- 机械
- MC Flow Factor 1
分类
模型格式 rfa
适配软件
特点
上传时间 2020-06-28
构件有问题？点我反馈
构件品牌 开利空调
