规格
19XR-303132HUBU52
- 尺寸标注
- E0 229mm
- C1__ve -1036.5mm
- Maintenance Zone Left Depth 4172mm
- MZONU__ve -2073mm
- Clearance Zone Height Depth 2073mm
- C0 92mm
- DI4 200mm
- A01 1965.5mm
- R2 100mm
- C1 1036.5mm
- Maintenance Zone Front Depth 1707mm
- R4 100mm
- C7 279.855010986328mm
- B1 853.5mm
- W3 5121mm
- B4 341mm
- Maintenance Zone Over Depth 2073mm
- W2D 99.9999999999999mm
- Maintenance Zone Under Depth 2073mm
- C3 210.712493896484mm
- DI3 200mm
- Maintenance Zone Back Depth 1707mm
- C9 303.176239013672mm
- C5 1513.5mm
- DI1 200mm
- R3 100mm
- C 2073mm
- Maintenance Zone Right Depth 4172mm
- C6 466.424987792969mm
- L3 12516mm
- B01 816mm
- L2D_Min 0mm
- C2 468.25mm
- D0 387mm
- A1 2086mm
- A2 3747mm
- B3 406.25mm
- L2D 99.9999999999999mm
- R1 100mm
- B2 426.25mm
- DI2 200mm
- 可见性
- Maintenance Zone Bottom Visibility 0
- Maintenance Zone Right Visibility 0
- Maintenance Zone Front Visibility 0
- Maintenance Zone Back Visibility 0
- Maintenance Zone Left Visibility 0
- Clearance Zone Visibility 0
- Maintenance Zone Top Visibility 0
- 标识数据
- 部件代码 ---
- 型号 ---
- 制造商 ---
- 注释记号 ---
- 成本 ---
- 类型图像 ---
- 类型注释 ---
- URL ---
- 说明 ---
- 图形
- Use Minimum Symbol Size 0
- 机械
- MC Flow Factor 1
分类
模型格式 rfa
适配软件
特点
上传时间 2020-06-28
构件有问题？点我反馈
构件品牌 开利空调
