规格
30HXC350E
- 可见性
- Maintenance Zone Top Visibility 0
- Maintenance Zone Back Visibility 0
- Clearance Zone Visibility 0
- Maintenance Zone Right Visibility 0
- Maintenance Zone Left Visibility 0
- Maintenance Zone Front Visibility 0
- Maintenance Zone Bottom Visibility 0
- 尺寸标注
- Maintenance Zone Right Depth 5430mm
- L3 16290mm
- Y1 920mm
- Y3 700mm
- B 379mm
- L2D_Min 0mm
- C2 305.575012207031mm
- Maintenance Zone Over Depth 4224mm
- A1 334.5mm
- E 2112mm
- C1 359.5mm
- Y4 520mm
- L2__ve -5150mm
- W3 3150mm
- Y5 400mm
- W1 525mm
- G 364mm
- Y6__ve -500mm
- L2 5150mm
- Y1__ve -920mm
- S1 100mm
- R2 80mm
- Y6 500mm
- Y2__ve -820mm
- L4__ve -4656mm
- Maintenance Zone Left Depth 5430mm
- W2D 99.9999999999999mm
- R3 100mm
- S 200mm
- A 290mm
- R1 100mm
- A2 284.325012207031mm
- Maintenance Zone Back Depth 1050mm
- Y4__ve -520mm
- Y5__ve -400mm
- L2D 99.9999999999999mm
- Y2 820mm
- D 309mm
- R 200mm
- C 340mm
- F 1315mm
- MZONU__ve -2112mm
- L4 4656mm
- B1 189.5mm
- E1 200mm
- E3 16.5mm
- L1 2715mm
- Maintenance Zone Under Depth 2112mm
- Y3__ve -700mm
- H 2747mm
- Maintenance Zone Front Depth 1050mm
