规格
30XW1762P
- 可见性
- Maintenance Zone Bottom Visibility 0
- Maintenance Zone Top Visibility 0
- Maintenance Zone Left Visibility 0
- Maintenance Zone Front Visibility 0
- Maintenance Zone Right Visibility 0
- Maintenance Zone Back Visibility 0
- Clearance Zone Visibility 0
- 尺寸标注
- I 1484mm
- DI4 250mm
- Maintenance Zone Right Depth 4809mm
- F3 473mm
- DI2 250mm
- A 347mm
- H2 672.5mm
- A5 463mm
- RI2 125mm
- DI3 250mm
- RI4 125mm
- F 604mm
- C1 214mm
- W3 6480mm
- D1 249mm
- Maintenance Zone Back Depth 2160mm
- L2D_Min 0mm
- W2D 99.9999999999999mm
- Maintenance Zone Left Depth 4809mm
- E1 305mm
- H1 872.5mm
- A3 313.5mm
- L3 14427mm
- F2 473mm
- L2D 99.9999999999999mm
- F1 473mm
- E3 610mm
- G1 1080mm
- RI3 125mm
- DI1 250mm
- Maintenance Zone Front Depth 2160mm
- A4 459mm
- E__ve -1586mm
- J2__ve -4479mm
- C 428mm
- J2 4479mm
- E 1586mm
- F4 767mm
- A6 439mm
- B 380mm
- D 349mm
- J1 2404.5mm
- RI1 125mm
- H 1745mm
- 标识数据
- 制造商 ---
- URL ---
- 类型图像 ---
- 部件代码 ---
- 类型注释 ---
- 成本 ---
- 注释记号 ---
- 型号 ---
- 说明 ---
- 图形
- Use Minimum Symbol Size 0
- 机械
- MC Flow Factor 1
